EBS PCF-PG10 PREMIUM GOLD FLAT PATCH CABLE 10 cm

kr 109

Bestillingsvare

Varenummer: 520007 Kategori: GTIN/EAN/UPC: 7332100072100
Brands:EBS

Beskrivelse

THE PREMIUM GOLD FLAT PATCH CABLE IS THE MOST LUXURIOUS SERIES OF EBS FAMOUS FLAT PATCH CABLES.

If you have ever struggled with limited space on your pedalboard, we share the pain with you. To end the frustration we’ve designed the truly unique, super compact and affordable EBS Flat Patch Cables.  Cables that won’t let you down on sound and flexibility, and at the same time reduce the space needed between pedals to a minimum. The elegant Premium Gold (PG) series are the most exclusive and features 24K Gold plated contacts with even smaller housing than the original EBS PCF-Deluxe (PCF-D) cables.

Double shielded cables and very low resistance keep your signal path clean and strong all the way through the pedalboard.

Extremely compact size and flexible cables ensure effective use of ALL space on your pedalboard.

Available in four lengths to cover your needs; 10, 18, 28 and 58 cm.

Since the introduction, these cables have made thousands of customers happy. We hope you will become one of them too.* Buy the cables at local stores and online dealers all over the world. * Great customer reviews and very few reported failures from hundreds of thousands sold cables so far.

– Connecteurs : jacks coudés 90°

– Conducteur : 20x 0,12mm flexible, optimisé pour les signaux audio à faible voltage

– Résistance du conducteur :





Contact house: 24 Carat Gold Plated

Double Shield: Conductive PVC and Copper shield protect effectively from both LF and HF interferences.

Conductor: Flexible copper conductor low voltage audio signal system

Operating Temperature: -15ºC to +70°C

Outer Insulation: PVC (Polyvinyl Chloride)

Signal Copper Cores: 20 x 0,12mm

Signal Insulation:  PE (polyethylene)

Twisted Copper shield:  45 x 0,12mm

Capacitance Cond./Shield: < 10 pF/decimeters

Conductor Resistance: < 10 mOhm/decimeters

Dimensions:  5,3 x 2,5 mm (rectangular cable), 22,0 x 11,5 x 5,0 mm (contact house)

Tilleggsinformasjon

Vekt 0.4 kg
Dimensjoner 10 × 3 × 5 cm
